3.000m long, External Corner, 190mm x 190mm x 90°, Polyester Coated
This item is made to order. For competitive prices, fast lead times, further information or to place an order; please contact our friendly sales team of product experts:
Monday - Thursday: 8am - 5:30pm
Friday: 8am - 4pm
Interested in this product?
You can use the form below and email us to enquire about this non-stocked product.
Technical Specifications
- Length - 3.000m
- Dimensions - 190mm x 190mm
- Angle - 90deg
- Finish -Â Painted Polyester Coating
- Material - Galvanised Steel
- Thickness - 0.5mm
- Weight - 6.21kg
- Colour Side - External
- Lap - 100mm mimimum
- Edges -Â Welted
The external corner flashing, also known as a barge board or verge flashing, is to be used along down the sides of the roof to cap it off and give it a neater finish. They are made to a 90 degree angle which will fall flush on top of the sheets along the side of the run using a 22m stitcher to fix it to the roof sheet. These are manufactured in a plastisol finish with a leathergrain effect and are manufactured in a 0.7mm gauge to provide strength and rigidity.
- 3.000m external corner
- 200mm x 200mm x 90deg.
- Welted
- Available in Juniper Green (BS 12B29), Goosewing Grey (BS 10A05) & Vandyke Brown (BS 08B29)
- Plastic coated
- Lightweight & easy to handle
- Easy to install
- Colour matched to sheets
- Plastic coated for a stronger finish
- Welted for extra rigidty
Where do I use an external corner flashing?
An external corner flashing is used to cap the roof sheets at the sides of the roofs.
How much should I lap the external corners over one another?
You should have a minimum of 150mm for lapping the ridges.
How do I fix the external corner flashing?
You want to use the stitchers screws to stitch the external corner flashing to the top of the corrugation that the external corner flashing projects out to .
Can I get different sized flashings?
Yes, we can manufacture made to order flashings. If you want to make an enquiry, please contact our sales team.
Can Southern Sheeting cut flashings?
Southern Sheeting will not cut stock flashings. Made to order flashings can be cut to different lengths and girths.
